AirCat 1300-TH-A 3/8" Composite Impact Wrench 600 ft-lbs

AirCat

SKU:
ARC1300-TH-A
Condition:
New
Availability:
Please contact us at 800-562-4791 for pricing and availability.

AirCat 1300-TH-A 3/8" Composite Impact Wrench 600 ft-lbs

The 1300-TH uses the rugged and reliable Twin Hammer mechanism - better suited for all-around automotive use.

The TWIN HAMMER Mechanism consists of 2 hammers in a closed cage which rotates around the anvil. This design allows the hammer to hit at the same time on both sides of the anvil. A twin hammer design is very durable and particularly suitable for long operating cycles. A further advantage is that the design consists of few individual parts and this makes it very easy to service. The twin hammer is lubricated by grease. Lubrication can be easily done from outside via greasing fitting without opening the housing. The TWIN-Hammer design is best used for industrial, all-around automotive applications, tire service and assembly.

Features

  • Provides 450 ft-lb maximum torque and 600 ft-lb of loosening torque
  • Super Clutch Twin Hammer Mechanism
  • Durable composite housing
  • Patented ergonomically designed housing
  • Patented quiet tuned exhaust (86 dBA)
  • Patented easy operation flip lever forward and reverse

Specifications

Length (in.)  6.75
Width (in.)  2.3
Height (in.)  6.6
Weight (lbs.)  2.63
Bolt Capacity (in.)  1/2
Loosening Torque (ft-lbs)  600
Working Torque (ft-lb)  70-315
Air Cons. (CFM)  6
Rec. Hose Size (in.)  3/8
Air Inlet (in.) NPT/BSP  1/4 NPT
Vibration Level (m/sec2)  10.5
Noise Level d(B)A  86.3
Square Drive (in.)  3/8
Free Speed (RPM)  10000
Impacts Per Minute (IPM)  1750
Max. Torque (ft-lb)  450

Downloads

pdf.jpg Manual

pdf.jpg Specs Sheet

Aircat Warranty

AIRCAT and NITROCAT air tools are warranted to be free from defects in material and workmanship for 2 years from date of purchase. We will repair or replace; at our option any defective part or unit which proves to be defective in material or workmanship during this 2 year period. The foregoing obligation is AIRCAT and Florida Pneumatic's sole liability under this or any implied warranty, under no circumstances shall it be liable for any incidental or consequential damages.

This warranty applies to the tool only. The warranty does not apply to any attached accessories/consumable products; such as drill chucks, sander backing pads, air hammer retainers and chisels or “kit” accessories or any other accessory included with the tool.

Any repair due to normal wear and tear, abuse, misuse, modification of the tool or repair attempts (by other than an AIRCAT or Florida Pneumatic Authorized Service Center) are not covered by this warranty.

Return your tool to an AIRCAT or Florida Pneumatic Authorized Service Center freight prepaid. Be sure to include your name, address, copy of purchase with date and description of the suspected defect.

AIRCAT whose policy is continued product improvement reserves the right to make changes in design or construction at any time without incurring any obligation on tools previously sold.

Tune-Up and Head Kits for all AIRCAT PNEUMATIC impact wrenches and ratchets are available. For Authorized Service Centers, please visit www.aircat.com



Aircat 2 Year Warranty
