Zinko Zatj-22S 22 Ton Air/Hydraulic Service Floor Jack Short Design


Sales taxes apply to California, Indiana, Ohio, Pennsylvania & Georgia. Please contact us at 800-562-4791 for pricing and availability.

Zinko Zatj-22S 22 Ton Air/Hydraulic Service Floor Jack Short Design


  • Lightweight and built for heavy-duty use.
  • All-steel welded construction makes our ZATJ reliable, long lasting and leak free.
  • The built-in safety valve prevents use beyond the rated capacity and lifting limit.
  • Air pump allows fast quiet operation.
  • An extension screw for fine adjustment is included. Extension adapters are also available separately.
  • When connected to standard shop air pressure providing 102-145 psi, these jacks can quickly obtain rated lift capacity with air-actuated operation.
  • The two large rubber-tire wheels and 3 position locking T-handle make these jacks easy to fit in many lifting situations.


 Capacity (Tons)   22
 Minimum Height (in)   8.07
 Hydraulic Lift (in)   4.13
 Maximum Heights (in)   15.94
 Chassis Length (in)   24.00
 Chassis Width (in)   12.60
 Height of Frame (in)   6.69
 Operating (psi)   102-145
 Screw Extension (in)   3.74
 Weight (lbs)   85.000000



Single Page Flyer

Parts Breakdown

User Manual


ZINKO makes every effort to assure that its products meet high quality and durability standards and warrants to the original retail consumer/purchaser of our products that each product be free from defects in materials and workmanship as follows:

1 year limited warranty on all ZINKO products unless specified otherwise. Warranty does not apply to defects due directly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities or to a lack of maintenance. ZINKO LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD SPECIFIED ABOVE FROM THE DATETHE PRODUCT WAS PURCHASED AT RETAIL. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES ORMERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOWLONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

In no event shall ZINKO be liable for incidental or consequential damages. The liability of ZINKO on any claim for loss or damage arising out of the sale, resale, or use of a jack or related service equipment shall in no event exceed the purchase price. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTALOR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

To take advantage of this warranty, the product or part must be return for examination, postage prepaid, to an Authorized Repair Station designated by our Ontario, California office. Proof of purchase date and explanation of the complaint must accompany the merchandise. If our inspection discloses a defect, ZINKO will either repair or replace the product or refund the purchase price if we cannot readily and quickly provide a repair or replacement, if you are willing to accept such refund. ZINKO will return repaired product or replacement at ZINKO expense. If it is determined there is no defect, or that the defect resulted from cause not within the scope of ZINKO warranty, then the user must bear the cost of storing and returning the products. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For service contact your local distributor.
