Zinko ZABJ-22PA 22 Ton Air Hydraulic Bottle Jack (J)

Zinko ZABJ-22PA 22 Ton Air Hydraulic Bottle Jack (Standard). Air Hydraulic Bottle Jack. 22 ton, Air Pressure Range 80-140 psi. Turn ordinary manual bottle jack power into air-hydraulic power. When connected to your shops air lines, these versatile jacks can safely deliver lifting power with the ease of a button to lift heavy beams, machines, platforms, and other objects.


  • Welded steel construction reduces metal fatigue allowing for a long service life
  • Forged steel base increases resistance to high pressure and increases durability
  • Oil bypass system prevents lifting ram from overextending
  • Safety valve protects hydraulic system from over-load damage
  • In-line filter screen located in air valve prohibits the entrance of contamination into the air hydraulic system
  • Comes with an air vent valve to stop pressure from bleeding in reservoir


Capacity (Tons)  22
Lift Time by Air Supply - No Load  50
Lift Time by Air Supply - Load  195
Air Pressure Range (psi)  80 - 140
Minimum Height (in)  10.50
Ram Lift (in)  6.00
Screw Extension (in)  3.00
Maximum Heights (in)  19.50
Weight (lbs)  36.000000


Single Page Flyer
Parts Breakdown
User Manual
