Description
JET Tools 723544OSCK JWDS-2244OSC Oscillating Drum Sander
The JET 723544OSCK (model JWDS-2244OSC) is an oscillating drum sander driven by a 1-3/4 HP motor with a 5-inch aluminum drum. The variable-speed drum oscillates left to right to minimize scratch patterns and reduce belt loading and burning, and it mounts on an enclosed mobile cabinet with SandSmart load monitoring.
Features
- Self-Cooling Drum.
- Exclusive variable speed oscillating drum moves from left to right—minimizing visual scratch patterns in workpieces and increasing the lifespan of abrasive paper.
- Infinitely variable speed control of up to 10 feet per minute allows the user to choose the optimal feed rate.
- Mobile cabinet features a heavy duty 45" x 24" footprint to increase stability and has a door to keep items stored securely.
- One rotation of the top-position hand wheel adjusts the drum height by 1/16".
- Precision-machined and dynamically balanced extruded aluminum drum is designed to dissipate heat and has 3/4" of oscillating stroke.
- Redesigned conveyor system pulls the work piece through the sander instead of pushing.
- Snipe is virtually eliminated thanks to the adjustable tension rollers that apply downward pressure to the work piece.
- Tool less abrasive take-up clips make changing abrasives quick and easy.
Specifications
| Stock Number | JT-723544OSCK |
| Drum Diameter (In.) | 5 |
| Dust Port Outside Diameter (In.) | 4 |
| Maximum Board Thickness (In.) | 4 |
| Minimum Board Length (In.) | 2-3/8 |
| Minimum Board Thickness (In.) | 1/32 |
| Model Number | JWDS-2244OSC |
| Motor Amps | 15 |
| Motor Power (HP) | 1-3/4 |
| Recommended Circuit Size (Amps.) | 20 |
| Weight (Lbs.) | 311 |
Manual
Warranty Information
WARRANTY INFORMATION
JET RED ASSURANCE 2-YEAR WARRANTY
JET warrants every product it sells. If one of our tools needs service or repair, one of our Authorized Service Centers located throughout the United States can give you quick service. In most cases, any of these JPW Industries Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or perform routine maintenance and major repair on your JET Tools. For the name of an Authorized Service Center in your area call 1-800-274-6848.
JET RED ASSURANCE 2-YEAR WARRANTY
JET warrants every product it sells. If one of our tools needs service or repair, one of our Authorized Service Centers located throughout the United States can give you quick service. In most cases, any of these JPW Industries Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or perform routine maintenance and major repair on your JET Tools. For the name of an Authorized Service Center in your area call 1-800-274-6848.
