Hofmann EELR709APKG 12K Scissor Alignment Lift w/ 2 Rolling Jacks, Turntables, Roll back kit
- Brand:
- Hofmann
- SKU:
- EELR709APKG
- Condition:
- New
Factory Shipped
Factory Shipped
Hofmann EELR709APKG 12K Scissor Alignment Lift w/ 2 Rolling Jacks, Turntables, Roll back kit
The Hofmann 12k Scissor Alignment Lift is a rugged 12,000 lb capacity scissor alignment lift with open front design that provides easy access to alignment service and calibration areas.
“Pro-Style” 24" wide runways provide easy drive-on for large vehicles. Hydraulic equalization and full support rear member deliver repeatable smooth level lifting. Flush mounted rear slip plates with heavy-duty encapsulated bearings support and offer smooth movement to ease rear alignment adjustments.
Features
- Part Number: EELR709APKG
- Adjustable turnplate pocket depth ensures level positioning of turnplates
- Expandable approach ramps provide multi tiered drive on approach to suit vehicle clearance and bay length. Extends up to 87". Retracts into itself 35" minimum
- Each heavy duty rolling jack is easy to position and provides 6,000 lbs of wheelfree® lifting
- Lifts straight up - no for or aft movement
- Cross aligned heavy duty hydraulic cylinders maintain constant level lifting with supporting reinforcing rear mount cross member
- Dual engaging twin interlocking mechanical safety racks with pneumatic release
- Smooth lift operation with captured re-enforced glide blocks
- Single point safety lock release system
- Compact, enclosed control console
- On-board Filter/Regulator/Lubricator (FRL) protects air systems
- Powder coat finishing with non-skid runway platform surface
- Certified to the current ANSI/ALI ALCTV:2011 lift standard
- *Note: Flush mount model version available here: EELR724APKG
Specifications
| Capacity | 12000 lbs |
| Lifting times | 95 s |
| Lowering times | 45 s |
| Lifting height | 70 inch |
| Power supply | 230 VAC 1Ph 50/60 Hz |
| Weight | 6615 lbs |
| Width Between Runways | 40 inch |
| 4 Wheel Alignment Wheelbase | 89 - 158 inch |
| 2 Wheel Alignment Wheelbase | 165 inch |
| Console Dimensions DxWxH | 16.5 x 14.125 x 45.75 inch |
| Air Supply Requirements | 90 - 140 Psi |
| Service Wheelbase | 179 inch |
| Overall Width | 90 inch |
| Lifting Speed | 95 s |
| Lowering Speed | 45 s |
| Runway Width | 23 inch |
Downloads
Hofmann has been a partner to automotive garages and tire shops for decades. For more than 80 years our name has been synonymous for delivering precision, quality and innovative garage equipment. It is our goal to provide the latest technology and user-friendly features to meet the needs of automotive service professionals.
Hofmann equipment Warranty Policy
Hofmann USA products carry the following warranties:
1. HOFMANN WHEL BALANCERS:
- LABOR 6 MONTHS
- PARTS 1 YEAR
- ELECTRONIC CIRCUIT BOARD 3 YEARS
- ELECTRIC MOTOR 5 YEARS
2. HOFMANN BRAKE LATHES:
- LABOR - 6 MONTHS
- PARTS - 2 YEARS
- ELECTRIC MOTOR - 1 YEAR
3. HOFMANN TIRE CHANGERS:
- LABOR - 6 MONTHS
- PARTS - 1 YEAR
- ELECTRIC MOTOR - 3 YEARS
- AIR MOTOR - 1 YEAR
- TRANMISSION - 3 YEARS
4. HOFMANN WHEEL ALIGNERS:
- LABOR - 6 MONTHS
- CIRCUIT BOARDS, PC’S, CRT & LCD - 3 YEARS
- PARTS & PRINTER - 1 YEAR
5. HOFMANN LIFTS:
- LABOR - 1 YEAR
- PARTS - 1 YEAR
- POWER PACK - 18 MONTHS (1 YEAR SCISSOR ALIGNMENT)
- HYDRAULICS - 1 YEAR
