Bendpak HD-7W 7,000 Lbs Extra Wide, Extra Tall 4-Post Lift

The 7,000-lb. capacity HD-7W is ideal for shops that want the versatility to park sports cars, sedans, light-duty trucks and SUVs in the same structure. There's even enough side clearance to accommodate larger truck mirrors. Even so, this lift is only slightly larger than a typical parking space. Due to its reduced footprint, as well as its ability to house a variety of vehicle types in a low-ceiling garage, the HD-7W is an extremely attractive parking and maintenance solution for both homeowners and professional technicians.

Features

7,000-lb. maximum lifting capacity.
Wide drive-thru with tall lifting height and short runways.
Runways include rail-kit for optional accessories.
Electric / hydraulic power system.
Single hydraulic cylinder mounted underneath runway.
Internal anti-sway slider blocks in each column.
Oversized self-lubricating cable rollers.
Features heavy-duty 3/8" aircraft cable.
Rugged 1.25" roller axles.
Multi-position safety locks in each column.
Adjustable lock ladders.
Ramps feature non-skid surface.
Push-button pneumatic safety release.
Optional 4,500-lb. capacity rolling jack available (Model RJ-45).

Specifications

	Lifting Capacity	7,000 lbs. (3,175 kg)
	Max Capacity / Front Axle	3,500 lbs. (1,588 kg)
	Max Capacity / Rear Axle	3,500 lbs. (1,588 kg)
A	Min. Runway Height	5 in. (127 mm)
B	Max. Rise	81 in. (2,056 mm)
C	Max. Lifting Height	87.25 (2,181 mm)
D	Overall Width (baseplate to baseplate)	110.25 ±.125 in. (2,800 ±3.1 mm)
E	Outside Length	174 in. (4,418 mm)
F	Overall Length	200.5 in. (5,093 mm)
G	Height of Columns	100 in. (2,537 mm)
H	Distance Between Posts	100.25 in. (2,546 mm)
I	Drive-Thru Clearance	86.5 in. (2,201 mm)
J	Runway Width	19 in. (482 mm)
K	Length of Runways	158.25 in. (4,019 mm)
L	Width Between Runways	35 in. (887 mm) or 41.25 in. (1,045 mm)
M	Runway Centerline	56.75 in. (1,445 mm) or 61.0 in. (1,603 mm)
N	Outside Edge of Runways	75.75 in. (1,927mm) or 82 in. (2,085 mm)
	Rated Capacity	115 in. (2,921 mm)
	75% Capacity	95 in. (2,413 mm)
	50% Capacity	80 in. (2,032 mm)
	25% Capacity	65 in. (1,651 mm)
	Locking Positions	17, spaced every 4 in. (102 mm)
	Lifting time	≈35 seconds
	Motor	220 VAC / 60 Hz / 1 Ph
	Max normal operating pressure	3,200 PSI
	Power Unit PRV setting	3,550 PSI
	Sound pressure (when raising/lowering)	<70 dBA
	Air supply	3 to 25 cfm at 50 to 150 psi
