AMGO Hydraulics PRO-12A 12000 Lbs Aligment 4-Post Lift
The PRO-12A, with a 12,000 lb lifting capacity, provides wheel service maintenance with integrated rear slip plates and it has adjustable turn plate pockets to fit various wheelbases.
Features
- Turn plates must be purchased separately
- 12,000 lbs Capacity
- Air-Lock Released for Safety and Reliability of Convenient Operation
- Mechanical Self-Lock and Cable-Breaking Protection
- 1/2 “Aircraft at Quality Cable
- Hydraulic cylinders are designed and made to high quality standards
- Skid Proof Diamond Platform
Optional Rolling Jacks:
More choices:
- -Optional led lights: No. 40103
- -Optional extension kits: No. 40901
- -Optional air line kits: No. 40102
• Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on Electrical Components.
Specifications
| Model | PRO-12A |
| Style | Alignment |
| Lifting Capacity | 12,000 lbs (5,500kg) |
| Lifting Time | 63S |
| A: Overall Length (Inc.Ramps) | 236 5/8″ (6012mm) |
| B: Overall Length (No.Ramps) | 200 3/4″ (5100mm) |
| C: Overall Width | 126 1/4″ (3208mm) |
| D: Width Between Columns | 112 1/4″ (2852mm) |
| E: Max. Lifting Height | 75 3/8″ (1915mm) |
| F: Overall Height | 86″ (2185mm) |
| G: Minimum Height | 8 5/8″ (220mm) |
| H: Max. Underneath Height | 67 7/8″ (1724mm) |
| I: Drive-Thru Clearance | 98 3/8″ (2498mm) |
| J: Width Between Runways | 43 1/4″ (1100mm), Max. 51 1/8″ (1300mm) |
| K: Outside Edge of Runways | 83 1/4″ (2116mm), Max. 91 1/8″ (2316mm) |
| L: Min. Four Wheel Align | 78 3/4″ (2000mm) |
| M: Max. Four Wheel Align | 155 7/8″ (3960mm) |
| N: Max. Two Wheel Align | 161 3/8″ (4100mm) |
| Gross Weight | 2,901 lbs (1,316kg) |
| Motor | 2.0HP, 220V/60Hz Single Phase |
Shipping Information
Downloads
Warranty information.
AMGO offers one of the best product warranties in the industry from the original factory commercial invoice date in the industry as follows:
1.Steel structure components(including Columns,Carriage,,Lifting Arms, Top Beam, Floor Cover,Platform,Cross Beam,Car Drive-in Ramp, Scissor,baseframe etc.) warranty for five years.
2.Hydraulic parts (including cylinders, oil seal, oil hose, fitting etc.)warranty for two years.
3.Other parts(no including consumption parts such as rubber pad),electrical components, power unit warranty for one year.
Warranty procedure:
In order to start a warranty claim, you need fill out completely (including date of purchase) the warranty card attached below, and then send it to technical.support@amgohyd.com. If this information is not provided, the factory will not support the claim.
Click here to download the warranty card
