Ranger RP-20FC Industrial 10-Ton Oil Filter / Can Crusher
Ranger’s RP-20FC oil-filter crusher is capable of applying 10 tons of force to virtually any used oil filter or can. With it you can easily reduce filters to 20% - 25% of their original size, as well as remove up to 95% of the oil. The RP-20FC includes an integrated collection chamber, collector downspout, and a stand to make all of your oil recovery tasks a walk in the park.
Features
- Save on disposal costs and storage space
- Fulfills EPA and other mandated environmental standards
- No-mess design operates clean and efficiently to lessen spill hazards
- Single-control valve operation
- Exclusive X-shape bevel in press head pre-aligns filters for absolute vertical press
- Welded steel plate construction
- 12.5" diameter cylinder providers a maximum crushing pressure of 20,000 lbs.
- Crushes cans in only 20 seconds
- Reduces filters to 25% of their original size
- Removes up to 95% of the oil
- 100% air operated for minimal maintenance
- Automatic safety door stops operation when opened
- Transparent door for a convenient view of the crushing process
- Pressure regulator and air moisture separator come standard
Included RP-20FCS oil filter crusher stand
- Rugged metal construction holds in excess of 230 lbs.
- Designed especially for the Ranger RP-20FC Oil Filter Crusher
- Area beneath stand accommodates 5 – 55 gallon storage tanks or trashcans
- Safely and efficiently keeps storage barrels out of the way
- Easy to setup
- Overall height: 42" (1,067 mm)
- Overall width: 27.75" (705 mm)
- Overall depth: 17.75" (451 mm)
- Unit weight: 72 lbs. (33 kg)
Specifications
| Overall Height | 29.5" (749 mm) |
| Overall Width | 17" (432 mm) |
| Overall Depth | 17" (432 mm) |
| Chamber Opening Height | 10.25" (260.35 mm) |
| Chamber Opening Width | 8" (203 mm) |
| Chamber Opening Depth | 11" (279 mm) |
| Average Cycle Time | 15 – 20 sec |
| Air Input | 125 – 175 psi |
| Unit Weight | 326 lbs. (148 kg) |
| Shipping Dimensions |
43'' x 22'' x 22'' (1,092 mm x 558 mm x 558 mm)
|
Stand included
The stand is sporting a durable metal construction which is recommended for use with the Ranger RP-20 FC oil filter crusher. Its design accommodates 5, 16 and 55-gallon used oil storage tanks, and the tanks fit even when they're positioned on top of drum dollies. As for the residual oil sludge will drain right into your storage tank. Don’t worry about dealing with barrels of oil littering your shop. The stand is crafted from robust metal and can hold over 230 lbs. of oil. Setup is as easy as can be, even if you are a novice when it comes to shop equipment. Not to mention that by using this setup you'll find your shop has more space and is safer.
If you need even more crushing power, the RP-50FC is Ranger’s latest and most powerful oil filter crusher yet, offering 50,000 lbs. of crushing force. (*Sold Separately)
