Zinko ZABJ-12C3 12 Ton Air/Manual Bottle Jack

Air Hydraulic Bottle Jack - 12 ton, cast iron base. Turn ordinary manual bottle jack power into air-hydraulic power. When connected to your shop's air lines, these versatile jacks can safely deliver lifting power with the push of a button, for lifting of heavy cars, trucks and other applications.


  • Operates both manually and pneumatically
  • Fast and efficient air pump saves lifting time; built-in safety valve to prevent overload
  • Heat treated extension screw and release valve adds extra strength and life span
  • Extremely strong and well designed swivel head bolt with 360° movement to prevent hose binding
  • Spring coil protectors on both ends to prevent punctures
  • Rust preventive coating on ram and extension screw
  • Convenient push button flap type air operation valve
  • Durable ductile iron base with 3 piece zinc plated handle
  • Properly placed welded carrying handle for easy transport


Capacity (Tons)  12
Lift Time by Air Supply - No Load  40
Lift Time by Air Supply - Load  125
Air Pressure Range (psi)  40-140
Minimum Height (in)  9.69
Ram Lift (in)  5.88
Screw Extension (in)  3.13
Maximum Heights (in)  18.69
Weight (lbs)  29.000000



ZINKO makes every effort to assure that its products meet high quality and durability standards and warrants to the original retail consumer/purchaser of our products that each product be free from defects in materials and workmanship as follows:

1 year limited warranty on all ZINKO products unless specified otherwise. Warranty does not apply to defects due directly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities or to a lack of maintenance. ZINKO LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD SPECIFIED ABOVE FROM THE DATETHE PRODUCT WAS PURCHASED AT RETAIL. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES ORMERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOWLONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

In no event shall ZINKO be liable for incidental or consequential damages. The liability of ZINKO on any claim for loss or damage arising out of the sale, resale, or use of a jack or related service equipment shall in no event exceed the purchase price. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTALOR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

To take advantage of this warranty, the product or part must be return for examination, postage prepaid, to an Authorized Repair Station designated by our Ontario, California office. Proof of purchase date and explanation of the complaint must accompany the merchandise. If our inspection discloses a defect, ZINKO will either repair or replace the product or refund the purchase price if we cannot readily and quickly provide a repair or replacement, if you are willing to accept such refund. ZINKO will return repaired product or replacement at ZINKO expense. If it is determined there is no defect, or that the defect resulted from cause not within the scope of ZINKO warranty, then the user must bear the cost of storing and returning the products. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For service contact your local distributor.
