Zinko ZPE-753HS-1 Electric Pump, 3-Way Manual Standard Valve, 2.64 Gal Oil Tank
Features
- The 753 series come equipped with a pressure gauge and are enclosed with a cooling fan for heavy-duty operation without overheating.
- Adjustable pressure regulator allows easy pressure adjustment. 3. Oil level indicator provides easy monitoring of oil level.
- Eye lit holes for convenient mounting on to fixture.
- Standard size comes with a 3-way manual valve to use with the single-acting cylinders. 3 ways-Advance/Hold/Retract, 2-way solenoid valves also available upon request.
- 4 way/3 position valve to use with the double-acting cylinders.
- Designed to easily accept various kinds of stacking valves such as solenoid valves, relief valves, and check valves.
- Easy to operate mounted electrical box for on/off operation, remote pendant switches also available upon request.
Specifications
| Model Number | Motor (50/60Hz) | Performance | Reservoir | |||||||
| Type | AC (V) | Output (HP) | Revolution (rpm) | Max. Press (psi) | Output (in3/min.) | |||||
| 2nd Stage | 1st Stage | 2nd Stage | 1st Stage | Capacity Gallons | Usable Gallons | |||||
| High | Low | High | Low | |||||||
| ZPE-753 | E | 220 | 1 | 2 | 10 | 1015 | 27.5 | 244 | 2.3 | 1.63 |
| For Use With | Model No.ZPE | Valve | Wt (lbs) | |
| Type | Function | |||
| Single Acting Cyliner | ZPE-753HS-1 | 3 Way manual Standard | A single acting ram is actuated by 3-way manual valve. Advance/Hold/Retract | 110 |
LIMITED WARRANTY
ZINKO makes every effort to assure that its products meet high quality and durability standards and warrants to the original retail consumer/purchaser of our products that each product be free from defects in materials and workmanship as follows:
1 year limited warranty on all ZINKO products unless specified otherwise. Warranty does not apply to defects due directly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities or to a lack of maintenance. ZINKO LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD SPECIFIED ABOVE FROM THE DATETHE PRODUCT WAS PURCHASED AT RETAIL. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES ORMERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOWLONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
In no event shall ZINKO be liable for incidental or consequential damages. The liability of ZINKO on any claim for loss or damage arising out of the sale, resale, or use of a jack or related service equipment shall in no event exceed the purchase price. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTALOR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
To take advantage of this warranty, the product or part must be return for examination, postage prepaid, to an Authorized Repair Station designated by our Ontario, California office. Proof of purchase date and explanation of the complaint must accompany the merchandise. If our inspection discloses a defect, ZINKO will either repair or replace the product or refund the purchase price if we cannot readily and quickly provide a repair or replacement, if you are willing to accept such refund. ZINKO will return repaired product or replacement at ZINKO expense. If it is determined there is no defect, or that the defect resulted from cause not within the scope of ZINKO warranty, then the user must bear the cost of storing and returning the products. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For service contact your local distributor.
* MODEL AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
