Martins Industries MW-60-4WAY Automatic Inflator High Flow 150 PSI x 4 - 4 Hoses 8'
One, two, three or four tires can be inflated or deflated at the same time with the Flatematic 4 way. Once connected to the valves, the tire inflator will automatically start inflation or deflation to precisely reach the identical pressure for all tires. Its higher airflow ensures the same great efficiency when inflating 4 tires than the other automatic tire inflators of the Flatematic series. All four hoses are equipped with clip-on chucks making tire inflation more productive by allowing you to work away from the tires.
Features
- Inflate or deflate up to 4 tires simultaneously and automatically up to 145 psi.
- Wall-mounted unit equipped with 4 air hoses of 8’ / 2.4 m.
- Only 4 min. 12 sec. to inflate 4 x 11R22.5 tires from 0 to 100 psi / 6.89 bar.
- Loud audible signal warns that the tires have reached the desired pressure.
- 4 measurement units (psi, bar, kPa, kg/cm2), Over pressure system, LCD screen & backlight.
Note: Air compressor required (Sold Separately)
Included
- 4 air hoses of 8’ with 1/4” NPT closed chucks.
- Quick coupling 1/4'' industrial.
- Air hose support hook.
- M6x38 screws (5x).
- User manual.
Specifications
| Features | Fixed, Wall-mounted, High-Flow, Over pressure setting (OPS), Inflate/deflate 4 tires at a time |
| Materials | Aluminium |
| Color | Black and orange |
| Air compressor required | Yes |
| Air pressure - max. outlet (psi) | 145 |
| Air pressure - max. inlet (psi) | 150 |
| Reading accuracy (psi) | 0.29 |
| Airflow - max. (l/min) | 3600 |
| Airflow - max. (CFM) | 128 |
| Hose quantity | 4 |
| Hose length (inches) | 96 |
| Hose length (cm) | 240 |
| Chuck type | Closed |
| Certifications | CE |
| Calibration certified | Yes |
| Autocalibration | Yes, on every unit start |
| Maintenance & calibration service | Yes |
| Degree of protection | IP66 |
| Supply voltage | 110 |
| Temperature range | -10 °C ~ 50 °C / 14 °F ~ 122°F |
| Product dimensions - LxWxH (inches) | 9 x 10 1/2 x 3 1/2 |
| Product dimensions - LxWxH (cm) | 23 x 27 x 9 |
| Net weight (kg) | 6 |
| Net weight (lb) | 14 |
| Package dimensions - LxWxH (inches) | 12 x 12 x 9 |
| Package dimensions - LxWxH (cm) | 31 x 31 x 23 |
| Gross weight (kg) | 45053 |
| Gross weight (lb) | 17 |
Downloads
LIMITED PRODUCT WARRANTY
Martins Industries warrants to the original purchaser that its products are free from defects in material and workmanship. This coverage is valid for a period of 6 months to 3 years, depending on the product, starting from the billing date. The warranty will be voided if the product has sustained damage due to misuse, improper assembly, poor maintenance, any accident or any non-authorized modifications / repairs.
If you any other doubts please contact us at 800-562-4791.
