Corghi BC200S Motorcycle/ATV Tire Changer + Wheel Support Kit + Sm Wheel Mounting Roller
Semi-automatic MOTORCYCLE line tyre changers suitable for professional and intensive use on motorcycle, scooter, go-kart and garden equipment wheels, as well as also on very thick wheels such as quad wheels. Variable height bead breaking unit to always work in an ergonomic and effective position.
Features
- Clamping: Horizontal side tilting arm and manual clamping of the vertical tool arm.
- Turntable: The turntable has three different clamping positions, which are easily selectable without tools, for clamping wheels from 5” to 23”.
- Bead Breaking: Horizontal bead breaking system.
- 3 Positions Wheel Support: Wheel support movable in 3 different positions with maximum opening of 14.5" (370 mm) to handle particularly high profile tires such as ATV/quad tires.
Specifications
| Technical Data | BC200S |
| Max. Wheel Diameter | 39.37" (1000 mm) |
| Std Clamping Capacity w/ATV kit | 6" - 16" |
| Bead-Breaking Blade Force | 750 kg |
| Maximum Wheel Width w/Bead Breaker Support | Pos 1 - 7.5" (190 mm) Pos 2 - 11" (280 mm) Pos 3 - 14.5" (370 mm) |
| Turntable Rotation | 8 - 15 rpm |
| Operating Pressure | 8-10 bar (116-145psi) |
| Power Unit | 230V 1ph 0.75kW - 230-400V 3ph 0,55kW |
| Weight | 330.69 lbs (150 kg) |
Downloads
CORGHI USA Limited Warranty
General Terms
Corghi USA expressly warrants its products will be free from defects in material and/or workmanship for the time period specified. Corghi USA must be informed in writing within 7 days after discovery of a defect. Corghi USA reserves the right to repair or replace a product at our discretion. Co nsumable products and accessories such as but not limited to; plastic protection parts, bead breaker pads, inflation hoses, and rollers, are not covered under this warranty.
This warranty does not cover any damage resulting from abuse or failure to perform any necessary maintenance (i.e. damage due to or resulting from, faulty installation, neglect, misuse, improper electrical connections or electrical surges, problems resulting from excessive water, contaminated air system, or pollutant of any nature, fire or freight damage).
Corghi machines are warranted to be free of defects as follows:
Tire Changers:
A2030, A2024TI, 2024TI LL, A9824TI, A9824 LLTI, A9830, A9222TI, Service Pro 124, Service Pro 324 - 2 year parts and 1 year labor. Transmission – 10 year part only (5 year part only on 9220TI).
AM50, AM500, AM5000, AM26, Master J, Master Code, Master28 – 2 year parts and 1 year labor.
HD700, AG52L, HD1200, Monster TT – 2 year parts and 1 year labor.
NOTE: Rubber Pads, air lines, gauges, mount/demount heads, and swabs - 90 day warranty
Tire Balancers:
PL60, Service Pro 750, EM9250, EM9280, EM9580, EM9550, EM9980C, Eyelight – 2 year parts and 1 year labor.
ET66, ET88 – 2 year parts and 1 year labor.
Alignment Machines/Specialty Equipment:
2 year parts and 1 year labor.
Disclaimer & Limitation on Liability.
Corghi USA agreement to repair a tire changer or balancer is expressly in lieu of all other warranties, express, implies or statutory, including any warranties for merchantability and fitness for a particular purpose. Corghi USA maximum liability shall be limited to the cost of the machine. In no event shall Corghi USA be responsible for owner’s lost profits, goodwill or other incidental or consequential damages. Corghi USA is not responsible for equipment or accessories damages in shipment. Freight claims are to be made directly with the carrier. We will be more than happy to assist you with any questions regarding filing claims.
