Challenger Lifts BT3300 Battery Lift Table 3300 Lb
The BT3300 features an adjustable and tilting top surface to efficiently remove and install electric vehicle batteries and battery packs up to 3,300 lbs. Comes standard with stackable rubber footpads, a rubber mat for the top plate, and fastener slots spaced 4" apart that are pre-tapped for OEM-specific adapters.
The BT3300 will increase your shop’s productivity, with its ability to handle a wide range of electric vehicle batteries from different manufacturers and complies with ASME PASE®-2019 Standards.
Used to facilitate and safely perform the installation and removal of EV batteries, electric car battery packs, transmissions, gearboxes, clutches, engines and various components of the car chassis.
Features & Benefits
- Scissor-style lifting
- Hydraulic cylinder
- Max reachable height 76.5”
- Easy maneuvering, thanks to pallet-jack style handle
- Extending, adjusting and tilting top plate
- Plugs in to any 120v outlet
- Power cord included
- Complies with ASME PASE-2019
Specifications
| Model Number | BT3300 |
| Lifting Capacity | 3,300 lbs. |
| Rise Height | 76.77” |
| Collapsed Height | 29.53” |
| Platform Height Adjustment | 1.77” |
| Platform Angle Adjustment | 6° |
| Platform Length | 68.54-81.34” |
| Platform Width | 31.5” |
| Deck Length | 59.06” |
| Base Height | 8.07” |
| Wheel Diameter | 7.87” |
| Overall Length | 116.375” |
| Motor | 2HP |
| Power Supply |
110v, 60Hz, Single Phase
|
| Current Draw | 14 Amps |
| Control Voltage | 24v |
| Hydraulic Pressure | 3,625 psi |
| Safety Limit Switch | Yes |
| Full Stroke Time (Rated Load) | 45s/70s |
| Full Descent Time (Rated Load) | 55s |
Downloads
Crafting automotive lifts to the highest standards. We're not just lifting vehicles, we're raising the standards for an entire industry.
Challenger Lifts Warranty Agreement
Challenger Lifts, Inc. lifts are guaranteed to the original owner. CLI shall repair or replace, at CLI option, for the full warranty period those parts that prove upon inspection to be defective and pay for reasonable costs of transportation and/or labor for replacement of said parts for the warranty period stated below. This warranty shall not apply unless the product is installed, used and maintained according to CLI’s specifications set forth in CLI’s installation, operation and maintenance instructions. Use of any unapproved parts or accessories will void your warranty. This limited warranty extends only to the original purchaser and is not transferable. This warranty is valid only if the product has been registered with Challenger Lift, Inc., www.challengerlifts.com.
This warranty does not cover normal maintenance or adjustments, damage or malfunction caused by improper handling, installation, abuse, misuse, negligence, carelessness of operation, or normal wear and tear. In addition, this warranty does not cover equipment when repairs have been attempted or made by anyone other than a CLI authorized service representative.
This warranty is exclusive and is in lieu of all other warranties expressed or implied including any implied warranty of fitness for a particular purpose, which implied warranties are expressly excluded. No employee, agent, representative, dealer or other person or entity is authorized to give any warranties of any nature on behalf of CLI.
The remedies described are exclusive and in no event shall CLI, Inc. be liable for special, consequential or incidental damages for the breach of or delay in performance of the warranty. This warranty shall be governed by the Commonwealth of Kentucky, and shall be subject to the exclusive jurisdiction of the Court in the Commonwealth of Kentucky in the County of Jefferson.
Functional parts are any wear items, as defined from time to time by Challenger Lifts. Examples include power units, cylinders, sheaves, hoses, cables, controls, etc. and may differ depending on the model of lift.
Structural parts are items, as defined from time to time by Challenger Lifts, Inc. that are not Functional Parts and include items like carriage, columns, arms, runways, plungers, etc. and may differ depending on the type of lift.
Note: WARRANTY CARD MUST BE COMPLETED AND RETURNED UPON INSTALLATION FOR VALIDATION or WARRANTY PERIOD WILL BEGIN FROM INVOICE DATE OF LIFT PURCHASE. WARRANTY MAY ALSO BE VALIDATED BY REGISTERING ONLINE @ challengerlifts.com/register.shtml
| Description | Model/Series | Labor | Functional Parts | Structural parts | Extended Warranty Available |
| CL10 | CL10 | 1 Year | 2 Years | 5 Years | Yes |
| 10K 2-Post, 9K 2-Post | LE10, SA10, CLFP9 | 1 Year | 1 Year | 5 Years | No |
| 12K, 15K, 18K 2-Post | CL12, 15000, 18000 | 1 Year | 2 Years | 5 Years | Yes |
| 8K Inground | EVW0820 | 1 Year | 2 Years | 2 years | No |
| 10K Ingrounds | EV1020 | 1 Year | 2 Years | 5 Years | Yes |
| 12K, 15K Ingrounds | EV1220, EV1520 | 1 Year | 1 Year | 5 Years | Yes |
| 14K 4-Post | 4P14 | 1 Year | 1 Year | 5 Years | No |
| 15K 4-Post | 4015 | 1 Year | 2 Years | 5 Years | No |
| 30K 4-Post Cable Drive | 4030 | 1 Year | 2 Years | 5 Years | No |
| 30K, 40K, 60K Chain Drive | 44030, 44040, 44060 | 1 Year | 1 Year | 1 Year | No |
| Rolling Jacks | RJ, SAJ | 1 Year | 1 Year | 1 Year | No |
| Mid and Short Rise | MR-6, SRM-10 | 1 Year | 1 Year | 1 Year | No |
| Scissors | SX14, DX77 | 1 Year | 1 Year | 1 Year | No |
| Mobiles | CLHM | 1 Year | 1 Year | 5 Years | No |
| Accessories | 90 days | No | |||
| Replacement Parts | 90 days | No |
Extended Warranty
An extended warranty is available for purchase for NEW CL/EV Series lifts. The Extended Warranty must be purchased within 30 days of lift invoice, and extends the Functional Parts coverage by an additional 3 years (5 Years total). Lift must be installed by and authorized Challenger installer. Extended warranty does not apply to accessories.
