JMC Equipment JMC8K-DX 8,000 Lb Deluxe Series Storage/ Service Four Post Lift
The JMC Equipment 8,000 Four Post Storage Lift is ideal for heavy-duty storage requirements at 8,000 lbs capacity. It features cable driven control with single point manual lock release, and adjustable locking positions for safety and convenience. Steel approach ramps are durable, and it is designed to fit in most residential garages. It also includes drip trays, jack tray, and a caster kit that’s poly, giving you a complete kit to all vehicle storage and servicing. With overall length with ramp of 207-5/16", width of 103-1/2", and height of 86", it is space efficient, and robust at the same time.
Standard Accessories
 |
Comes with a standard jack tool tray. |
 |
The Poly Caster Kit comes in a set of 4, extremely easy to install and will have you the lift rolling around the shop with ease. |
 |
Comes with 3 Lightweight polyethylene drip trays |
Optional Accessories
 |
These ramps are made out of lightweight yet strong aluminum which makes them easy to lift. |
 |
This bracket enables you to mount the power unit on most 4 post lifts to the outside of the column. |
Features
- 8,000 lbs Capacity.
- Cable driven.
- Single Point Manual Lock Release.
- Adjustable Locking Positions.
- Slack Cable Safety.
- Steel Approach Ramps.
- Fits in most residential garages.
- Includes Drip Trays, Jack Tray & poly Caster Kit.
Specifications
| Lift Model | JMC8K-DX / FP8k-DX |
| Capacity | 8,000 lbs |
| Overall Length w/Ramp | 207-5/16″ |
| Overall Width (Outside Base Plates) | 103-1/2″ |
| Overall Height | 86″ |
| Lifting Height | 74-3/4″ |
| Width Between Posts | 94-1/2″ |
| Length of Runways | 165-1/2″ |
| Width of Runways | 18-5/8″ |
| Lifting Speed | 90S |
| Maximum Clearance under Track | 70″ |
| Cable Diameter | 3/8″ |
| Base Plate Size | 10″ x 12″ |
| Lock Position | 10 |
| Ship Weight | 1,705 lbs |
| Power | 115V – 20 Amp – 1PH |
Downloads
*The manufacturer collects Sales Tax on all orders shipped to California
TUXEDO DISTRIBUTORS LIMITED WARRANTY
Structural Warranty:
The following parts and structural components carry a five year warranty:
Columns, Arms, Uprights, Swivel Pins
Legs, Carriages, Overhead Beam
Tracks, Cross Rails, Top Rail Beam
Limited One-Year Warranty:
Tuxedo Distributors, LLC (Tuxedo) offers a limited one-year warranty to the original purchaser of Lifts and Wheel Service equipment in the United States and Canada. Tuxedo will replace, without charge, any part found defective in materials orworkmanship under normal use, for a period of one year after purchase. The purchaser is responsible for all shipping charges. This warranty does not apply to equipment that has been improperly installed or altered or that has not beenoperated or maintained according to specifications.
Other Limitations:
This warranty does not cover:
1. Parts needed for normal maintenance
2. Wear parts, including but not limited to cables, slider blocks, chains, rubber pads and pulleys
3. Replacement of lift and tire changer cylinders after the first 30 days. A seal kit and installation instructions will be sent for repairs thereafter.
4. On-site labor
Upon receipt, the customer must visually inspect the equipment for any potential freight damage before signing clear on the shipping receipt. Freight damage is not considered a warranty issue and therefore must be noted for any potential recovery with the shipping company.
The customer is required to notify Tuxedo of any missing parts within 72 hours. Timely notification must be received to becovered under warranty.
Tuxedo will replace any defective part under warranty at no charge as soon as such parts become available from the manufacturer. No guarantee is given as to the immediate availability of replacement parts.
Tuxedo reserves the right to make improvements and/or design changes to its lifts without any obligation to previously sold, assembled or fabricated equipment.
There is no other express warranty on the Tuxedo lifts and this warranty is exclusive of and in lieu of all other warranties,expressed or implied, including all warranties of merchantability and fitness for a particular purpose.
To the fullest extent allowed by law, Tuxedo shall not be liable for loss of use, cost of cover, lost profits, inconvenience,lost time, commercial loss or other incidental or consequential damages.
This Limited Warranty is granted to the original purchaser only and is not transferable or assignable.
Some states do not allow exclusion or limitation of consequential damages or how long an implied warranty lasts, so the above limitations and exclusions may not apply. This warranty gives you specific legal rights and you may have other rights, which may vary from state to state.
