Boxo ATA540111-R 54" 11-Drawer Elite Series Bottom Roll Tool Cabinet (Gloss Red)

The Elite Series Tool Storage solution is our premium top-of-the line tool box offering from BoxoUSA. It is the prime choice for the enthusiast who settles for nothing but the best.

The 54" 11-Drawer Bottom Roll is a Gloss Red Body and Silver Drawer Pulls built with 15-Gauge Heavy-Duty Steel to offer the utmost of durability. The Elite Series is built to last with box beam construction featuring gusset reinforced corners, full length beam supports and strategically placed spot welds. Powder coat paint is applied to all exterior and interior surfaces to resist chipping, scratching and fading for a lasting finish.

Roll Cabinet dimensions are: 53-13/16" W x 25-5/8" D x 48-1/4" H

The full length drawers are built extra deep to compliment larger items that would otherwise not fit into smaller boxes. Each full length drawer includes; heavy-duty 220 lbs. drawer slides (either single or double depending on the depth of the drawer), full length drawer pulls have built-in style drawer locking latches which are integrated in the handle with quick-release drawer function. Each extruded aluminum handle is anodized for superior protection during prolonged use.

Protect your tools with a robust single barrel key locking mechanism to offer you peace of mind. Every Elite Series tool roll cabinet incorporates only the best 3300 lbs. 6" x 2" shock absorbing casters with 360° swivel function. These specialized casters are utilized to allow for rolling over irregular surfaces while carrying a full assortment of tools. This proven design allows for every Elite Series tool roll cabinet a lifetime of use.

Mount the heavy-duty pull handle to either side of the box. An EVA work surface mat and drawer liner set is included.

Drawer Dimensions are: (3) Full Width Drawers (1) 47.72" W x 22" D x 4.88" H and (2) 47.72" x 22" D x 3.23" H.

(4) Left Drawers: (1) 29.84" W x 21" D x 2.44" H, (2) 29.84" W x 22" D x 5" H and (1) 29.84" W x 22" D x 7.64" H.

(4) Right Drawers: (1) 13.27" W x 21" D x 2.44" H, (2) 13.27" W x 22" D x 5" H and (1) 13.27" W x 22" D x 7.64" H.

Weight: 660 lbs. Storage Capacity: 30,980 Cubic Inches

Shipping weight: 702 lbs. (includes pallet)

• Heavy-duty 15-gauge steel
• Box beam construction features gusset reinforced corners and full length beam supports (pictured)
• Powder coat paint applied to all exterior and interior surfaces with anodized aluminum drawer pulls and trim
• Soft close heavy-duty steel ball bearing drawer slides rated at 220 lbs. Per slide with quick drawer release
• Double 220 lb. ball bearing slides in deep or heavy bearing drawers
• Full length drawer pulls have built-in style drawer locking latches which are integrated in the handle
• Single barrel key lock system secures all drawers
• 3300 lbs. capacity heavy-duty 6" x 2" shock absorbing lockable casters with 360° swivel function
• Left or right mount ergonomic handle
• Lifetime warranty
