Omer Lifts KAR Pantograph Alignment Lift
Lift Styles
- KAR 54 - L: 196"/16’.3” - Above Ground w/ one-way ramps ALI Certified @ 14,000lbs capacity - 220V 1ph 60Hz - Includes Rolling Jack Rail - Includes Center Hose Cover - Includes Front Pocket Recesses for Turning Plates - Includes Rear Pneumatic Slip-Plates.
- KAR 72 - L: 220” / 18’.3’ Platform lift version.Above Ground w/ one-way ramps ALI Certified @ 16,000lbs capacity - 220V 1ph 60Hz - Includes Rolling Jack Rail - Includes Center Hose Cover - Includes Front Pocket Recesses for Turning Plates - Includes Rear Pneumatic Slip-Plates.
- KAR 82-L: Electro-hydraulic lift, vertical rise lift, capacity 18.000 lbs. 236""/20' length - Above Ground w/ one-way ramps - ALI Certified @ 18,000lbs capacity - 220V 1ph 60Hz - Includes Rolling Jack Rail - Includes Center Hose Cover - Includes Front Pocket Recesses for Turning Plates - Includes Rear Pneumatic Slip-Plates.
- KAR 82 - LTS: Alignment Lift Package w/ Integrated lift tables (No accessories) Above Ground Versions L- 20’ 18,000 lbs. Capacity. C Alignment Deck with 2x lift Table, one-way.
Description
The KAR Lift Alignment has been designed to a higher standard of quality; it is manufactured in Mirano Italy by O.ME.R S.p.A., a world leader in Lift Manufacturing for over 40 years in an ISO 9001 facility, and equipped with a premium Siemens 3HP/2.2kw motor and a BOSCH pump. Its superior structural strength provides longer life and more precise alignments. The multipiece boxed style runway structure will not flex or sag. The new patented ASO (Absorbing System Omer) system prevents, through a special leverage and a device for absorbing loads, any type of deflection, torque or mechanical stress on the runways and on the bases due to uneven distribution of load on the lift.
This alignment rack provides greater flexibility with now more models to choose from. It is available in surface or flush-mounted, alignment or service deck. An optional 9,000lb. (4T) runway lifting tables can also be added to the unit, with standard jacking beam rails provided. The platform length can also be customized form 16 to 20 ft. The fixed points (only four) on which the lift is leaning, are positioned at the end of the runaways, thus allowing a complete customization of the structure's length.
The KAR Lift Alignment offers lower maintenance costs than many other similar lifts in the market. The steel components are “wheel-a-brator” shot blasted and a hot dip acid washed is applied before a “double bake” powder coat finish is applied. Moreover, a zerk style grease fittings is added at all hinge points, to help facilitate easy maintenance. An optional hot dip galvanization of complete structure is also offered for extreme wet conditions. A low pressure hydraulics provides longer life; four low pressure inverted cylinders are mounted under the runway for protection. The cylinders operate at <3800psi/260bar at full capacity. Additional premium options and accessories useful to expand its capabilities and service life are: stainless steel radius plates, built-in tire inflation hoses, removable work steps, LED runway lighting, and premium heavy-duty extended life 5-year warranty HD jacking beams.
The precision leveling feature offered by this alignment rack provides more accurate alignments and the exclusive “volumetric” control maintains level to within less than 1/4 in. with no need of electronic sensors on the lift or PLC/PC Board. The synchronization system between the two runaways can be electro-hydraulic or electronic, depending on the model, ensuring the maximum reliability under all conditions of employment. The end-result is therefore perfect stability and superior alignment (coplanarity) of the system.
Designed for greater technician productivity this lift is designed with no obstructions between the runways or base frame. The large space that is created below the two runaways and all around the lift itself, allow the operators complete freedom of movement. The lift rises 81 in. in 71 seconds with 18 locking positions. The built in runway compressed air outlets are located in the front and in the rear. Furthermore, for the flush mount version of the lift, a new automatic and completely pneumatic system of pit covering plates has been developed. These plates, specially designed to support both the weight of the operator and that of his tools, allow for any type of work to be performed below the runaways.
All the KAR lifts are equipped with next-generation safety devices: mechanical jacks on each leg cylinder (housed in a protected position under the runaway itself), safety valve installed on each cylinder, photocell for control of alignment between the lift runaways, and pressure-relief valve.
Features
- Built to a higher standard of quality; - built in Mirano Italy by O.ME.R S.p.A. Premium Siemens 3HP / 2.2kw motor and BOSCH pump.
- Superior structural strength provides longer life and more precise alignments - Multipiece boxed style runway structure will not ex or sag. Purpose built hollow structure lifting legs.
- Greater flexibility with more models to choose from - Available in surface or ush-mounted, alignment or service deck. Optional 9,000lb. (4T) runway lifting tables with standard jacking beam rails provided.
- Premium options and accessories can expand its capabilities and service life - Stainless steel radius plates, built-in tire inflation hoses, removable work steps, LED runway lighting, and premium heavy-duty extended life 5-year warranty HD jacking beams.
- Lower maintenance costs -steel components are “wheel-a-brator” shot blasted and hot dip acid washed before a “double bake” powder coat finish is applied. Zerk style grease fittings at all hinge points. Optional hot dip galvanizing of complete structure for extreme conditions.
- Precision leveling feature provides more accurate alignments - exclusive “volumetric” control maintains level to within les than 1/4” /5mm. No electronic sensors are required on the lift or PLC/PC Board. No fault codes are required.
- Low-pressure hydraulics provides longer life -four low pressure inverted cylinders are mounted under the runway for protection. Cylinders operate at <3800psi/260bar at full capacity.
- Designed for greater technician productivity - there are no obstructions between the runways or base frame. The lift rises 81” / 2057mm in 71 seconds with 18 locking positions. Built in runway compressed air outlets front and rear.
Specifications
| Capacity | 18,000 lb. (8.2T) (Also available in 16,000lb. (7.3T and 12,000lb (5.5T) |
| Overall Length (Surface Mounted) | 259.1”, 275.6” or 291.3”/ 6581mm, 7000.2 or 7399mm |
| Runway Lengths | 17’, 18’ or 20’/ 5.2M, 5.5M or 6M |
| Runway Width | 25.6” / 1412.2mm |
| Overall Width | 87.4” to 98” / 2220mm to 2489.2mm |
| Collapsed Height | 11.4” / 290mm |
| Lifting/Lowering Time | 70 sec |
| Raised Height | 81” / 2057mm |
| Length of Rear Slip Plates | 91.1” / 2314mm |
| Maximum 4 wheel alignment | 185”, 197”or 205”/ 4699, 5004 or 5207mm |
| Minimum 4 wheel alignment | 75.5” / 1918mm |
| Maximum Service Wheel Base | 196”, 208” or 224”/ 4987.4, 5283.2 or 5689.6mm |
| Certification | ALI Certified - ANSI AL CTV 2011 |
| ISO Certified Factory | Yes |
| Control | Volumetric Hydraulic/Mechanical |
| Synchronization | Hydraulic Displacement with Torsion Bar |
| Noise Level | < 75 decibels |
| Power Requirement | 220 volt single phase 60hz - 20amp |
| Shipping Weight | 5,960 lbs / 2909kg |
| Finish | Double-Bake Powder Coat optional Hot Dip Galvanizing |
| Power Requirement | 3HP/ 2.2kw - 116psi/ 8 bar |
Optional Accessories (Sold Separately)
- KAR-TP-Stainless Steel Air Operated Turning Plates.
- KAR-RJ-9,000lbs Rolling Jacks.
- KAR-LR-LONG RAMPS.
- KAR-LED- LED Light Kit.
