JET Tools JDP-20MF, 20" Floor Drill Press 115/230V 1Ph
Precision, stability, and versatility are the benchmark features of the JET 20" drill press. This high-quality line of JET Drill Presses offers a greater range in spindle speeds than other machines of this class.
Features
- Spindle is supported by high quality ball bearings reducing rotational friction while increasing load support.
- Hinged metal belt and pulley cover coupled with quick adjustment motor mount allow rapid changing of spindle speeds.
- Adjustable tension spindle return spring.
- Large cast iron head.
- On/off switch located on front of the drill press head.
- Spindle guard.
- Built-in work lamp.
- 1/2" diameter external positive depth stop with three nut locking feature for quick adjustment.
- Adjustable tension spindle return spring.
- Rotating, 45° tilting, crank-operated worktable with quick release clamp.
- Drill chuck and key included.
Specifications
| Model Number | JDP-20MF |
| Base Dimensions (In.) | 13-3/4 x 22-3/4 |
| Base Work Table (In.) | 13 x 8-1/2 |
| Column Diameter (In.) | 3-3/8 |
| Distance Column to Spindle (In.) | 10 |
| Drilling Capacity Cast Iron (In.) | 1 |
| Drilling Capacity Mild Steel (In.) | 3/4 |
| Drills to Center of Circle (In.) | 20 |
| Motor (HP) | 1-1/2 HP, 115/230V, 1Ph |
| Number of Spindle Speeds | 12 |
| Overall Dimensions (L x W x H) (In.) | 33-1/2 x 18-1/2 x 67 |
| Range of Spindle Speeds (RPM) | 150 - 4,200 |
| Spindle Distance to Base (In.) | 46-3/4 |
| Spindle Distance to Table (Max.) (In.) | 29-1/8 |
| Spindle Taper (In. x TPI) | MT-3 |
| Spindle Travel (In.) | 4-5/8 |
| Style (Type) | Variable |
| T-Slot Centers (In.) | 3-1/2 |
| T-Slots Number and Size (In.) | 6 and 1/2 |
| Table Size (L x W) (In.) | 18-1/2 x 16 |
| Table Travel (In.) | 21-1/2 |
| Work Table Weight Capacity (Lbs.) | 80 |
| Weight (Lbs.) | 325 |
