JET Tools J-A5816, 15" Variable Speed Floor Model Drill Press 115/230V 1PH
These JET Drill Presses use a variable-speed motor with the stepped-pulley system, and come equipped with a continuously variable transmission. This enables use at a wide range of speeds, as well as the ability to change speed during operation. A scale-marked hand wheel that matches the desired machine speed is mounted to a reduction gearing system for precise operator control. This adjusts the gearing ratio between the motor's fixed pulley and the output shaft's variable pulley, changing the speed of the chuck. A tensioner pulley is implemented in the belt transmission to take up or release the slack in the belt as the speed changes.
Features
- Full bearing support on quill for maximum spindle stiffness.
- Handwheel speed adjustment of 400 to 5,000 RPM.
- Large 2-1/4" quill for greater accuracy.
- 3" column diameter for maximum head support.
- 6" stroke for deep hole application.
- Accurate depth stop for precise hole depths.
- 1/2" drill chuck and arbor included.
- Safety collar.
Specifications
| Model Number | J-A5816 |
| Drills to Center Circle (in.) | 15 |
| Drilling Capacity Cast Iron (in.) | 5/8 |
| Drilling Capacity Mild Steel (in.) | 1/2 |
| Column Diameter (in.) | 3 |
| Distance Column to Spindle (in.) | 7-1/2 |
| Spindle Travel (in.) | 6 |
| Spindle Distance to Base (in.) | 44-1/2 |
| Max Distance Spindle to Table (in.) | 25-3/4 |
| Table Size (in.) | 15 x 18 |
| Table Travel (in.) | 16-3/4 |
| T-Slots Number and Size (in.) | 2 & 1/2 |
| T-Slot Centers (in.) | 5-5/16 |
| Work Table Weight Capacity (lbs.) | 90 |
| Spindle Taper | MT-2 |
| Range of Spindle Speeds (rpm) | 400 - 5000 |
| Base Dimensions (L x W x H / in.) | 20-7/16 x 14-3/16 x 3-1/8 |
| Base Work Table (in.) | 12-1/8 x 11-13/16 |
| Base Slots Number & Size (in.) | 2 & 1/2 |
| Motor (HP) | 1HP, 115/230V, 1Ph |
| Overall Dimensions (L x W x H / in.) | 30 x 20 x 71 |
| Net Weight (lbs.) | 426 |
