Corghi MasterCode Base with arm Touchless Tire Changer (Elect. Only)

Half a century since the invention of the Artiglio and eleven years since the introduction of “Leva la leva” (leverless) technology, CORGHI sets the benchmark higher once again with the Artiglio Master Code.

With automatic wheel dimension acquisition enabling automatic tool positioning, and the invaluable Smart Corghi System demounting procedure, the Master Code rewrites the rule book for tire changers, demonstrating once again Corghi’s unrivalled ability to continuously steer the evolution of the sector.

The goals set for these new machines were to achieve an even higher degree of automatism, to increase performance and efficiency with all wheel types and to reduce the use of that increasingly precious commodity - time. The computerised Touch Screen system guides the operator through all procedures and suggests the best possible solution to any problem encountered.

Master Code is compatible with all tire types, from Run Flat-UHP tires to both small and large balloon tires. This latest creation from Corghi - The Only Innovator In The Tire Changer Segment - makes work safer, simpler and quicker for the tire service professional while ensuring total protection for the rim and tire.

Features

Available in electric only.
Wheel data self-acquisition
Smart Corghi system.
Dual bead breaker with controlled penetration.
Mobile control console.
Interactive touch screen.
New intelligent electromechanical turntable.
Integrated fully articulated lifter.
Bead depressor.
Lifter.
Latest generation inverter motor.
Ergonomic pedal controls.

Specifications

Technical Data	MasterCode
Max. Tire Diameter	47,2” (1200 mm)
Max Wheel Width	15"
Wheel Diameter	13” to 32”
Turntable Torque	885 ft/lb (1200 Nm)
Turntable Speed	7-20 rpm
Clamping	Automatic
Max Bead Breaking Range	19"
Upper Bead Breaking Force	1641.1 lbf (7300 N)
Lower Bead Breaking Force	1641.1 lbf (7300 N)
Wheel Lifter Load Capacity	187.4 lb (85 Kg)
Drive System	2-speed Inverter Motor
Power Requirements
Electric 1Ph	230V-0.98 kW 50Hz/60 Hz
Electric 1Ph (alternative)	115V-0.98 kW 50Hz/60Hz
Pneumatic operating pressure	116 to 145 psi (8 to 10 bar

Air Requirements	130 psi
Dimensions - Max	72.5" H x 69.3" W x 86.1" D
Weight	1,312 lbs.

*Note: The manufacturer reserves the right to modify the features of its products at any time.

Downloads

Flyer

Catalog

CORGHI USA Limited Warranty

Name: Corghi MasterCode Base with arm Touchless Tire Changer (Elect. Only)
Brand: Corghi
SKU: C-0-11108514/00
Price: 32833 USD
Availability: InStock

General Terms

Corghi USA expressly warrants its products will be free from defects in material and/or workmanship for the time period specified. Corghi USA must be informed in writing within 7 days after discovery of a defect. Corghi USA reserves the right to repair or replace a product at our discretion. Co nsumable products and accessories such as but not limited to; plastic protection parts, bead breaker pads, inflation hoses, and rollers, are not covered under this warranty.
This warranty does not cover any damage resulting from abuse or failure to perform any necessary maintenance (i.e. damage due to or resulting from, faulty installation, neglect, misuse, improper electrical connections or electrical surges, problems resulting from excessive water, contaminated air system, or pollutant of any nature, fire or freight damage).

Corghi machines are warranted to be free of defects as follows:
Tire Changers:

A2030, A2024TI, 2024TI LL, A9824TI, A9824 LLTI, A9830, A9222TI, Service Pro 124, Service Pro 324 - 2 year parts and 1 year labor. Transmission – 10 year part only (5 year part only on 9220TI).
AM50, AM500, AM5000, AM26, Master J, Master Code, Master28 – 2 year parts and 1 year labor.
HD700, AG52L, HD1200, Monster TT – 2 year parts and 1 year labor.
NOTE: Rubber Pads, air lines, gauges, mount/demount heads, and swabs - 90 day warranty

Tire Balancers:

PL60, Service Pro 750, EM9250, EM9280, EM9580, EM9550, EM9980C, Eyelight – 2 year parts and 1 year labor.
ET66, ET88 – 2 year parts and 1 year labor.

Alignment Machines/Specialty Equipment:

2 year parts and 1 year labor.

Disclaimer & Limitation on Liability.

Corghi USA agreement to repair a tire changer or balancer is expressly in lieu of all other warranties, express, implies or statutory, including any warranties for merchantability and fitness for a particular purpose. Corghi USA maximum liability shall be limited to the cost of the machine. In no event shall Corghi USA be responsible for owner’s lost profits, goodwill or other incidental or consequential damages. Corghi USA is not responsible for equipment or accessories damages in shipment. Freight claims are to be made directly with the carrier. We will be more than happy to assist you with any questions regarding filing claims.
