Cemb ER100GT High-Speed Diagnostic Wheel Balancer

CEMB

SKU:
ER100GT
Condition:
New
Availability:
Please contact us at 800-562-4791 for pricing and availability.
Shipping:
Free Shipping

Cemb ER100GT High-Speed Diagnostic Wheel Balancer

The new version of the CEMB top-of-the-range wheel balancer is even faster and more efficient.  In just 6,4 seconds and without any manual intervention on behalf of the operator the machine automatically detects all wheel dimensions, unbalance, internal and external wheel and rim eccentricity, tread-depth and conicity.

Features

  • 3D Laser Scan - Extraordinary accuracy and speed in 3D acquisition of wheel sizes with exact positioning of adhesive weights.
  • External Laser Scan - Complete wheel diagnosis including tyre conicity and wear analysis in three different areas.
  • Side Laser - Line laser indicator on the upper part of the wheel to ease the application of clip-on weights in the exact position.
  • OPB One Plane Balancing - Correction of both static and dynamic unbalance on one plane at once and with only one weight.
  • AutoAdaptive Mode - The new tolerance calculation system.
  • HubMatch - During the measuring cycle, the wheel’s "maximum eccentricity point" is detected and displayed on monitor, therefore allowing for its reduction during the re-mounting of wheel on vehicle.
  • Direct Matching - Visualization of the best possible matching to reduce eccentricity.
  • ALU-S Balancing Mode - Adhesive weights on the internal rim planes with specific counterweight position indicator (position repeater).
  • Tire Set - The software indicates the best wheel positioning on the vehicle to get the best ride (conicity) and to minimize wheel vibrations (eccentricity).
  • Automatic Positioning Speed Doubled and instantaneous locking of the wheel at the point of weights application.
  • Pneumatic Wheel Locking - Floor to floor time reduction / Extremely easy and quick to use / Very accurate wheel centering.
  • Print Report with QR Code for quick export and immediate integration with workshop systems.

Specifications

 Single phase power supply  230V/1ph/50 hz
 115V/1ph/60 Hz
 Max. absorbed power  0,15 kW
 Balancing speed  100 rpm
 Measuring cycle for 15 kg (33 lb) wheel  4.7 s
 Measurement uncertainty  ± 0,5 g
 Resolution  0,5 g
 Average noise  < 70 dB (A)
 Rim width setting range  1.5” ÷ 20” oppure 40 ÷ 510 mm
 Rim diameter setting range  10” ÷ 30” oppure 265 ÷ 765 mm
 Min./Max. compressed air pressure  7 ÷ 10 Kg / cm² / ~ 0.7 ÷ 1 Mpa
 ~ 7 ÷ 10 bar; / ~ 105 ÷ 145 psi
 Max. wheel weight  < 75 kg
 Machine weight  220 kg



Downloads

pdf.jpg Brochure

Warranty Information

  1. By finalizing the purchase agreement, the user confirms that the goods are ordered for purposes related to their business or professional activity.
  2. The duration of the contractual warranty of CEMB products to protect against any construction or operating defects and material defects is 12 (twelve) months from the date of delivery, unless otherwise agreed.
  3. CEMB will replace or repair the products or items supplied, or will totally or partially refund the price, if, despite correct and diligent use by the customer, defects are found not attributable to the installation or incorrect use of the product, which must be asserted against CEMB no later than 12 (twelve) months from the delivery date. Any defects that emerge during use in the first 12 (twelve) months must be immediately notified to CEMB.
  4. The customer undertakes to provide all the evidence regarding the reality of the defects or anomalies found. Likewise, the customer must provide CEMB with all the means to proceed to the ascertainment of such defects and to be able to remedy them. To ensure this latter purpose, the customer will refrain from his own intervention or from any third party intervention.
  5. The disputed goods must be returned to CEMB within 2 (two) weeks from the notification and must be properly packaged, with shipment at customer’s care and in accordance with the special instructions that CEMB may have given at the time of supply or subsequently. The items, or components or parts of them returned must be accompanied by a note stating the description of the defect, as well as any other information indicated or requested by CEMB at the time of supply or subsequently.
  6. The warranty does not apply to replacements or repairs that result from normal wear and tear of the products, from deterioration or accidents caused by negligence, or for use of the products other than that for which the devices are intended. In the same way, the warranty does not apply in the event of inadequate intervention by the customer or user on the products delivered.
  7. The repair, modification or replacement of parts during the warranty period cannot have the effect of extending the warranty period of the products. All other actions and claims covered by the warranty are excluded, especially those aimed at repairing direct or indirect damage caused to people or other objects other than the products delivered, as well as reimbursement of any loss of earnings.
  8. CEMB reserves the right to perform a detailed expert analysis of the products returned under warranty to determine the causes of the defect and communicate them to the customer before proceeding with any replacements, repairs, or refund calculation.
  9. Should the customer request a search for the origin of a fault in CEMB’s goods, to be carried out at its premises, the applicable expenses (travel, etc.) will be charged to the customer after a detailed estimate accepted by the latter before operation, and all this without CEMB being obliged to produce results.
  10. All products or articles or parts thereof replaced by CEMB will become the exclusive property of CEMB. This warranty replaces any warranty or other provision established by law regarding the quality or suitability of the products for specific uses, except for those provisions which by law cannot be waived.
  11. The liability of CEMB for all possible causes is limited to a sum which, in the absence of a different stipulation of the agreement, is limited to the contractual amount of the supply that gives rise to the complaint. The customer agrees to waive any recourse by his/her insurance companies against CEMB and the insurance companies of that company.
