Zinko RHC-5 5 Ton Ram Toe

Zinko

SKU:
RHC-5
Condition:
New
Availability:
Sales taxes apply to California, Indiana, Ohio, Pennsylvania & Georgia. Please contact us at 800-562-4791 for pricing and availability.

Zinko RHC-5 5 Ton Ram Toe

5 Ton Aluminum Toe Ram. Oil Capacity 11.20 in³. Widely used for bridge or plant construction, emergency lift for rescuer after earthquake or building corruption, and moving or installation of industrial machinery and shipyard equipment.

Features

  • These toe cylinders are designed to lift loads with a very low clearance. The toe area can pick up the load from as low as 0.88 inches, which is the lowest pick up point in the industry.
  • Easily connecting the port to any hand pump or air pump. These toe cylinders will give the operator full control of the lift from a distance whenever close quarters operation is not accessible. Coupler connection port can be operated at any direction.
  • 5 and 10 ton models come with steel cylinder.
  • 10 and 25 ton models come with aluminum cylinder lighter weight for mobility.

Specifications

Capacity (Tons)  5
Oil Capacity (in³)  11.20
Minimum Height - Toe (in)  0.87
Minimum Height - Head (in)  11.75
Maximum Height - Toe (in)  5.79
Maximum Height - Head (in)  16.67
Ram Lift (in)  4.92
Toe Area (in)  2.25 x 2.88
Base Area (in)  7.12 x 7.12
Weight (lbs)  42.000000

Downloads

Single Page Flyer

LIMITED WARRANTY

ZINKO makes every effort to assure that its products meet high quality and durability standards and warrants to the original retail consumer/purchaser of our products that each product be free from defects in materials and workmanship as follows:

1 year limited warranty on all ZINKO products unless specified otherwise. Warranty does not apply to defects due directly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities or to a lack of maintenance. ZINKO LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD SPECIFIED ABOVE FROM THE DATETHE PRODUCT WAS PURCHASED AT RETAIL. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES ORMERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOWLONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

In no event shall ZINKO be liable for incidental or consequential damages. The liability of ZINKO on any claim for loss or damage arising out of the sale, resale, or use of a jack or related service equipment shall in no event exceed the purchase price. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTALOR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.


To take advantage of this warranty, the product or part must be return for examination, postage prepaid, to an Authorized Repair Station designated by our Ontario, California office. Proof of purchase date and explanation of the complaint must accompany the merchandise. If our inspection discloses a defect, ZINKO will either repair or replace the product or refund the purchase price if we cannot readily and quickly provide a repair or replacement, if you are willing to accept such refund. ZINKO will return repaired product or replacement at ZINKO expense. If it is determined there is no defect, or that the defect resulted from cause not within the scope of ZINKO warranty, then the user must bear the cost of storing and returning the products. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For service contact your local distributor.

* MODEL AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
