EMAX 575CFM 3 PHASE 230 VOLT Refrigerated Air Dryer
Our EMAX air dryer is the only energy efficient dryer systems with aluminum refrigerated air inner cooler. The air is filtered of all solid particles 0.01 micron and larger. Clean, dry compressed air leaving the dryer minimizes maintenance and repair and also reduces internal dryer contamination. We designed them with Non-corrosive inner and after cooler.
Our dryers feature stainless steel heat exchanger for maximum dryer life and less maintenance. EMAX Air dryers are UL-CSA approved scroll compressor & electric system for high efficiency and durability. They feature adjustable hot bypass for complete dryer function in low and high CFM flow preventing dryer freeze up.
Features
- Keep Water, Oil, And Dirt Out of Your Compressed Air: Less corrosion of pipes and tools / Avoid splotches & stains.
- Energy Efficient Aluminum Refrigerated Air Cooling System: Designed for maximum performance and efficiency.
- Rust Free, Stainless Steel Heat Exchanger: Maximum heat transfer, maximum dryer life & less maintenance
- Refrigerated Air Inlet Inner Cooler: Provides trouble free operation for high temp cooling
- Compact And Efficient. 575 CFM, 37 - 50 Degree Dew Point.
- Easy Wiring. Uses 230 Volt Three Phase power.
More Features
- Purifies compressed air by chilling to condense moisture.
- Condensate is drained carrying oil & dirt partials away from the air.
- Auto drain system – eliminates the need for daily maintenance.
- Refrigerant pressure – gauge clearly monitors performance of dew point temp (models under 400 CFM).
- PLC Display (models 400 CFM & above).
- Outlet air baffle heater – prevents condensation on outlet air piping.
- Heavy duty steel cabinet.
- Trouble free operation refrigerated air inlet inner cooler for high temp cooling.
- Top mounted condenser & fan motor.
- Environmentally friendly 134A refrigerant.
- Auto Drain System.
- Refrigerant Pressure Gauge.
- Outlet Air Baffle Heater.
Specifications
| Dryer CFM | 575 |
| Dryer Dims | 27” x 31” x 55” |
| Dryer Weight | 500 LBS |
| Refrigerant Type | 134a |
| Dryer Drain Type | Built in automatic |
| Filtration | Built in Coalescing Filter |
| Dew point | 37-50 |
| Dryer Pipe size | 3" NPT |
| Max Rated Inlet Temp | 150 |
| Max Ambient Temp | 120 |
| Full load amps | 11.26 |
| Amp draw | 25 |
| Hertz | 60 |
| Phase | 3 Phase |
| Dryer Voltage | 230 |
| Dryer CFM | 575 |
| Refrigerant amount Ounces | 246 OZ |
| Noise level | 70 DBA |
| Normal working pressure PSI | 100 |
| Max Pressure | 230 |
| Auto Drain Timer cycle | Every 5 Min / 5 Second drain |
| Superheat of Thermostatic Expansion Valve | 41 F - 50 F |
| Evaporating Pressure | 29.7 PSI |
| Fan Pressure Switch | 130 - 174 PSI |
| Security High Pressure Switch | 162.5 PSI |
| Security Low Pressure Switch | 23.2 PSI |
| Refrigerant Temp. Switch | 113 F |
| Water Flow Valve | 159.5 PSI |
| Freight Class | 70 |
| Shipping DIMS | 48” X 32” X 64” |
| Shipping Weights | 655 LBS |
*Note: Specifications subject to change without notice
