iDEAL UTVKIT-MSC-6KLP UTV Adaptor Kit
The iDEAL UTV Adaptor Kit includes swing arm bracket adaptors specifically designed for the popular iMOBILE MSC-6KLP Single Column / Mobile Lift. The exclusive UTV Bracket Adaptor design reconfigures the iMOBILE Lift to raise & perform general service for most lighter and smaller sized vehicles such as Utility, Power Sport, Recreational & Custom type vehicles. The UTV Bracket Adaptors extends the Lift Pads ‘inner’ radius lifting area, while providing 360o adjustable width rotation. The UTV Adaptor Kit provides ideal & safe lifting for Inspections, Servicing and even Showcasing for most Utility / All-Terrain Vehicles, Golf Carts & Dune Buggies with an overall vehicle weight up to 2,600 lbs.
Features
- For use with the iDEAL MSC-6KLP 6,000Lbs Low Profile Mobile Single Column Lift
- 2,600 LBS Capacity (650 LBS per adaptor)
- FOR Utility, Power Sport & Recreational Type Vehicles
- Ideal for utility, power sport & recreational type vehicles
- Provides adjustable width / 360° bracket roation
- Extends Spin-Up Pad lifting range by 8.9" per arm
- Adjustable width / locking cradle base for lifting pads
- Kit design uses MSC- 6KLP 'Spin-Up' lift pads & height extensions
- Quick & easy installation & removal
- Durable powder-coat finish
Specifications
| Total Capacity (Set of 4) | 2,600 lbs. |
| Capacity Per Adaptor | 65 lbs |
| Swivel Pad Adaptor Height - Min/Max | 7-14" / 10-1/8" |
| Swivel Pad Adjustable Width Range | 8-7/8” |
| MS Arm & Adaptor Pad Range - Min/Max | 19-11/16" / 91" |
| OS Arm & Adaptor Pad Range - Min/Max | 26-3/16" / 82-5/16" |
| Bracket Adaptor Length | 14-3/8" |
| Bracket Adaptor Width | 4” |
| Bracket Adaptor Height | 3-1/2” |
| Ship Weight | 58 lbs. |
Ideal for most Utility, Power Sport & Recreational Vehicle Lifting
Tuxedo collects Sales Tax on all orders shipped to California
TUXEDO DISTRIBUTORS LIMITED WARRANTY
Structural Warranty:
The following parts and structural components carry a five year warranty:
Columns, Arms, Uprights, Swivel Pins
Legs, Carriages, Overhead Beam
Tracks, Cross Rails, Top Rail Beam
Limited One-Year Warranty:
Tuxedo Distributors, LLC (Tuxedo) offers a limited one-year warranty to the original purchaser of Lifts and Wheel Service equipment in the United States and Canada. Tuxedo will replace, without charge, any part found defective in materials orworkmanship under normal use, for a period of one year after purchase. The purchaser is responsible for all shipping charges. This warranty does not apply to equipment that has been improperly installed or altered or that has not beenoperated or maintained according to specifications.
Other Limitations:
This warranty does not cover:
1. Parts needed for normal maintenance
2. Wear parts, including but not limited to cables, slider blocks, chains, rubber pads and pulleys
3. Replacement of lift and tire changer cylinders after the first 30 days. A seal kit and installation instructions will be sent for repairs thereafter.
4. On-site labor
Upon receipt, the customer must visually inspect the equipment for any potential freight damage before signing clear on the shipping receipt. Freight damage is not considered a warranty issue and therefore must be noted for any potential recovery with the shipping company.
The customer is required to notify Tuxedo of any missing parts within 72 hours. Timely notification must be received to becovered under warranty.
Tuxedo will replace any defective part under warranty at no charge as soon as such parts become available from the manufacturer. No guarantee is given as to the immediate availability of replacement parts.
Tuxedo reserves the right to make improvements and/or design changes to its lifts without any obligation to previously sold, assembled or fabricated equipment.
There is no other express warranty on the Tuxedo lifts and this warranty is exclusive of and in lieu of all other warranties,expressed or implied, including all warranties of merchantability and fitness for a particular purpose.
To the fullest extent allowed by law, Tuxedo shall not be liable for loss of use, cost of cover, lost profits, inconvenience,lost time, commercial loss or other incidental or consequential damages.
This Limited Warranty is granted to the original purchaser only and is not transferable or assignable.
Some states do not allow exclusion or limitation of consequential damages or how long an implied warranty lasts, so the above limitations and exclusions may not apply. This warranty gives you specific legal rights and you may have other rights, which may vary from state to state.
