Bendpak XPR-10AS-168-LP 10,000 Lbs Low-Profile with Bolt-On Extension 2-Post Lift

Brand:
BendPak
SKU:
BP-5175402
Condition:
New

Factory Shipped

  • Ranger Rjs-1T 1,650-Lb.High Reach Jack Stand
  • Ranger Rd-9G 9-Gallon Upright Portable Oil Drain
Total Price:
$5,346.00 $4,415.00
(You save $931.00)
Free Shipping
Free Shipping

Factory Shipped

Bendpak XPR-10AS-168-LP 10,000 Lbs Extra Tall Clearfloor Low Profile 2 Post Car Lift

The powerful and secure XPR-10AS-168-LP is an incredibly rapid two?post lift with a robust menu of features to increase efficiency and productivity. Extended height columns provide added overhead clearance and an adjustable width design allows you to choose the best setting for your specific space or vehicle lifting requirements. This true asymmetric lift features 30 Degree rotated columns for added door-opening clearance and interior car access. The exclusive Tru-Metric carriage and arm design combines to give users the ability to load vehicles either symmetrically (centerline of vehicle at column) or asymmetrically (centerline of vehicle behind column).

Bendpak Direct Drive Technology Bendpak Tru Metric Lift System Bendpak XPR-10A-168 Floorplan

Bendpak Safe Balancing Bendpak Car Lift Guide Top 10 Car Lift Buying Guide

Features:



  • Lift arms shown with optional foot guards 10,000-lb. lifting capacity
  • Bolt-on 24" column extensions provide added overhead clearance
  • Expandable top beam accommodates wide or narrow drive-thru configuration
  • Padded overhead safety shutoff bar
  • Exclusive Tru-Metric arm design for more versatile arm positioning
  • 30 Degree rotated single-piece columns
  • Single-point safety release
  • Drop-end arms provide a lower pad height
  • Dual hydraulic direct-drive cylinders
  • Over-sized 53" tall carriage for superior strength and durability
  • Electric / hydraulic power system
  • Large, 17" x 19" A36 steel base plate
  • Self-lubricating dura-glide UHMW polyethylene bearing system
  • Safety locks in each column spaced every 3"
  • Automatic arm restraints
  • Heavy-duty 1/2" aircraft-quality equalizer cables
  • Oversized cable sheave diameter reduces cable fatigue
  • 4-piece 63mm stackable adapter set comes standard
  • Double-telescoping arm design
  • Versatile drop-in contact pads with stackable adapters
  • ALI approved.



Specifications:

MODELXPR-10?AS-168
Lifting Capacity* 10,000 Lbs. / 4,536 kg.
*Max Capacity / Front Axle 5,000 Lbs. / 2,268 kg.
*Max Capacity / Rear Axle 5,000 Lbs. / 2,268 kg.
A - Height Overall: 169" / 4,293 mm.*
B - Width Overall: (NARROW) 137" / 3,480 mm .
B - Width Overall: (WIDE) 145" / 3,683 mm.
C - Width Outside of Columns: (NARROW) 133" / 3,378 mm.
C - Width Outside of Columns: (WIDE) 141" / 3,581 mm.
D - Floor To Overhead Switch: 165" / 4,191 mm.*
E - Inside Columns: (NARROW) 104" / 2,642 mm.
E - Inside Columns: (WIDE) 112" / 2,845 mm.
F - Reach (Front Arm Min.): 23-1/2" / 597 mm.
G - Reach (Front Arm Max.): 45-1/2" / 1,156 mm.
H - Reach (Rear Arm Min.): 42-1/2" / 1,079 mm.
I - Reach (Rear Arm Max.): 60" / 1,524 mm.
J - Min. Pad Height: 4.25" - 6-3/4” / 108 mm. - 171 mm.
K - Rise: 69" / 1,753 mm.
L - Max Lift Height (Pad Only): 73" - 75" / 1,854 - 1,905 mm.
M - Max Lift Height (3" Adapter): 75.5" - 77.5" / 1,917 mm. - 1,968 mm.
N - Drive-Thru Clearance: (NARROW) 94" / 2388 mm.
N - Drive-Thru Clearance: (WIDE) 102" / 2591 mm.
Screw Pad Adjustment: 2" / 51 mm.
Motor (**) 220 VAC / 60 Hz. 1Ph.
Time of full Rise: 45 Seconds
Max Load Per Arm: 2,500 Lbs. / 1134 Kg.



ACCESSORIES

WSA-100        STEEL LIFT PAD            FRAME CRADLE PADS         RUBBER LIFT PADS

       WSA-100           STEEL LIFT PADS      FRAME CRADLE PADS          RUBBER LIFT PADS
