iDEAL PSB-AFOFB1388-3PH-230V-AK PSB AF Open Face Booth (ASY)

iDEAL

SKU:
PSB-AFOFB1388-3PH-230V-AK
Condition:
New
Availability:
Price is subject to change if the product is on backorder. Contact us at 800-562-4791 for availability.
Shipping:
Calculated at Checkout
Total Price:
MSRP: $8,398.80
$7,499.00
(You save  $899.80 )
Adding to cart… The item has been added
Shipping Calculated at Checkout Factory Shipped

iDEAL PSB-AFOFB1388-3PH-230V-AK PSB AF Open Face Booth (ASY)

The iDEAL ‘A-Frame’ Open Front Paint Booth is an economic, commercial grade open front paint booth designed to provide optimal ‘air flow’ with superior lighting for high-quality spray painting & finishing applications. The iDEAL Open Front Paint Booth is a great solution for industrial batch-type & automated production-type finishing systems. Air flows through the open front section of the booth, then passes through the work area towards the rear of booth into the filtered exhaust chamber. Filtered exhaust air is then drawn through the exhaust plenum & discharged upwards through the exhaust fan & ducting. Easily installed with heavy duty, precision punched 18 gauge panels allowing for quick nut & bolt assembly. Standard with bright  white powder-coat finish, deluxe control panel, premium exhaust filters, hinged glass light fixtures & high quality tuve-axial exhaust fan to complete the package for a premium, high-quality Open Front Paint Booth, all at a great value!

Exclusive Features!

  • ALWAYS IN STOCK, TYPICALLY SHIPS WITHIN 48 HOURS!
  • Deluxe control panel included
  • Durable Bright White Powder Coat Finish

Standard Features

  • Heavy Duty Precision Punched 18 Gauge Panels
  • Optimal Air Flow W/ Cfm 7,983@ .5 Static Pressure
  • Unique 'A-Frame' Commercial Grade Booth Design
  • Inside Opening Dimensions: 13'W X 8'-6"H X 7'-6"D
  • Convenient 5/16" Bolt & Nut Assembly
  • All Assembly Hardware,Manometer & Sealant Included
  • Ul Listed 24" Dayton Tube-Axial Exhaust Fan W/ Spark Resistant Fan Blades
  • Nema Rated 2Hp-3 Ph 230/460Vac-60Hz Motor Standard
  • Premium Afc Exhaust Filters
  • Superior Lighting With (2Ea) Ldpi Industrial Light Fixtures W/ Inside Access Hinged Glass Door
  • True 'Daylight Color' W/ Ge T8 48" Florescent Lamps 32W 5000K, 4 Lamp
  • Meets And/Or Exceeds All Applicable Osha & Nfpa 33 Regulations
  • Easy To Install, Operate & Maintain

Specifications

Paint Booth Model

PSB-AFOFB1388-AK

Inside Dimensions

13’W X 8-6”H X 7’-6”D

Outside Dimensions

13′-4″W X 8’-10″H X 10’-2″D

Fan / Motor

(1ea) – 24″ Tube Axial Fan
2HP-3PH-230/460VAC-60HZ
Non-Spark, NEMA Rated

CFM

7,983 @ .5 Static Pressure

Light Fixtures

(2ea) 48” 32W, T8 / 4 Bulb Light Fixtures

UL & ETL Listed Cls1, Div2 – Groups A, B, C & D

Lamps

(8ea) T8 Florescent, 32W, 5000K – 48”L

Options

1 Phase Electrical Configuration

8′ Exhaust Duct Kit (24″ Diameter)

LED Lighting Upgrade Kit

TUXEDO DISTRIBUTORS LIMITED WARRANTY

Structural Warranty:

The following parts and structural components carry a five year warranty:

Columns, Arms, Uprights, Swivel Pins

Legs, Carriages, Overhead Beam

Tracks, Cross Rails, Top Rail Beam

Limited One-Year Warranty:

Tuxedo Distributors, LLC (Tuxedo) offers a limited one-year warranty to the original purchaser of Lifts and Wheel Service equipment in the United States and Canada. Tuxedo will replace, without charge, any part found defective in materials orworkmanship under normal use, for a period of one year after purchase. The purchaser is responsible for all shipping charges. This warranty does not apply to equipment that has been improperly installed or altered or that has not beenoperated or maintained according to specifications.

Other Limitations:

This warranty does not cover:

1. Parts needed for normal maintenance

2. Wear parts, including but not limited to cables, slider blocks, chains, rubber pads and pulleys

3. Replacement of lift and tire changer cylinders after the first 30 days. A seal kit and installation instructions will be sent for repairs thereafter.

4. On-site labor

Upon receipt, the customer must visually inspect the equipment for any potential freight damage before signing clear on the shipping receipt. Freight damage is not considered a warranty issue and therefore must be noted for any potential recovery with the shipping company.

The customer is required to notify Tuxedo of any missing parts within 72 hours. Timely notification must be received to becovered under warranty.

Tuxedo will replace any defective part under warranty at no charge as soon as such parts become available from the manufacturer. No guarantee is given as to the immediate availability of replacement parts.

Tuxedo reserves the right to make improvements and/or design changes to its lifts without any obligation to previously sold, assembled or fabricated equipment.

There is no other express warranty on the Tuxedo lifts and this warranty is exclusive of and in lieu of all other warranties,expressed or implied, including all warranties of merchantability and fitness for a particular purpose.

To the fullest extent allowed by law, Tuxedo shall not be liable for loss of use, cost of cover, lost profits, inconvenience,lost time, commercial loss or other incidental or consequential damages.

This Limited Warranty is granted to the original purchaser only and is not transferable or assignable.

Some states do not allow exclusion or limitation of consequential damages or how long an implied warranty lasts, so the above limitations and exclusions may not apply. This warranty gives you specific legal rights and you may have other rights, which may vary from state to state.
