EMAX 5 HP 1 PH 80 Gallon Vertical With Air Silencer
Silent Air Quiet Air Compressor
Engineered and manufactured in the U.S.A. The whisper series compressors reduce stationary compressor DBA ratings by as much as 25%!
The Whisper dissipates compressor intake noise by channeling the intake air through a series of baffle plates and pre-filter media within the silencer cabinet. As a result, the piston intake noise is trapped and dissipated within the silencer structure. As a result, the piston intake noise is trapped and dissipated within the silencer structure. It also acts as a secondary filtration for cleaner air.
This Industrial 5 HP 2 Stage Inline 1 Phase Vertical 80 Gallon Piston Air Compressor is designed for up to 50,000 hours industrial use with proper maintenance. This unit features our low RPM pumps and delivers 19 SCFM @ 100 PSI. Our unit features automatic or continuous run functionality and is SUPER COOL & SUPER QUIET!
Features
- Pumps are SUPER quiet in operation and built to last!.
- Solid cast iron crankcase.
- Precision balanced solid cast iron crankshaft.
- Timken-Style stainless steel roller bearings on the front and rear of the crankshaft.
- Removable 100% cast iron cylinders.
- Built-in fan, head unloaders, inter-cooler and after-coolers.
- One of the lowest RPM compressor pumps on the market. That’s the Emax difference!.
- Not only do you get the big CFM output, but the lower RPM operation also reduces friction and heat buildup to extend pump life!.
- Large 1-3/8” output shaft.
- High quality ball bearings on the front and rear of the motor shaft.
- Large starting and running capacitors.
- 15 Service Factor load. This means the motor can be pulled 15% over full load for more break horsepower.
- Dynamically balanced armature for low vibration levels.
- Belt guards built right here in the USA with 13 G steel and premium grade expanded metal.
- For your safety, our belt guards are OSHA approved.
- Prewired condor starter and pressure switch built into one. Features an actuation- type diaphragm.
- Our air tanks are manufactured right here in the USA and are ASME code compliant in 50 states including California.
- 100% brass check valves with Teflon Seating.
- 100% brass ASME safety valves.
- Taper lock style 2-groove pulleys (not single groove).
- We also use dual 2-groove, B-Style belts to drive our pumps.
Specifications
CFM @ 100 PSI | 19 |
Compressor Stage | Two |
Pump RPM | 800 |
Pump Material | Solid Cast Iron |
Pump Model | APP2I0524TP |
Dimensions LxWxH | 42" x 34" x 75" |
Product Weight | 620 LBS |
Motor RPM | 1750 |
Motor Phase | Single |
Voltage available | 230 |
Tank Size | 80 Gallon |
Tank orientation | Vertical |
Tank Outlet Size | 3/4" |
Tank Drain | Manual |
Certifications | CSA, ASME,ETL |
Running AMP | 24 |
Recommended Breaker | 40 AMP |
Max PSI | 175 |
Oil Capacity | 2 Quarts |
Drive Type | Belt Driven |
Tank Size | 80 Gallon |
Shipping Length | 48" |
Shipping Width | 46" |
Shipping Height | 83" |
Shipping Weight | 850 LBS |
