EMAX Industrial 10 HP 80 gal. Two Stage Air Compressor

Our Industrial Series offers all the same quality and durability as our Plus series without all the extra cost of added features. We offer this series so that anyone can afford to have an EMAX Compressor.

EMAX Industrial 10 HP 2 Stage V4, 1 Phase vertical 80 gal. Piston Air Compressor is designed for up to 70,000 hours of commercial or industrial use with proper maintenance. This unit delivers 38 SCFM @ 100 PSI, top PSI of 175. Our unit features industrial ODP electric motors, condor pressure switch, manual ball valve tank drain, powder coated ASME tank 200PSI rating, all paired with all cast iron 70,000 Hr. rated patented pressure lubricated reciprocating pump.

Features

• Pumps are SUPER quiet in operation and built to last!.
• One of the lowest RPM compressor pumps on the market. That’s the Emax difference!.
• Spin-on oil Filter.
• Oil Pressure Gauge.
• Magnetic starter.
• Built in Inner-cooler and After cooler.
• Industrial-Duty, 1750 RPM (not 3450 RPM) Name Brand Motor –UL & CSA.
• ASME Certified Air Tank – Approved for ALL 50 states.
• Solid cast iron crankcase.
• Precision balanced solid cast iron crankshaft.
• Timken-Style stainless steel roller bearings on the front and rear of the crankshaft.
• Removable 100% cast iron cylinders.
• Built-in fan, head unloaders, inter-cooler and after-coolers.
• Top quality compression and oil rings.
• Precision ground pistons machined to tight tolerances ensures low oil carry over.
• Not only do you get the big CFM output, but the lower RPM operation also reduces friction and heat buildup to extend pump life!.
• These units have name brand OPD (open drip motors) on them.
• Large 1-3/8” output shaft.
• High quality ball bearings on the front and rear of the motor shaft.
• Large starting and running capacitors.
• 15 Service Factor load. This means the motor can be pulled 15% over full load for more break horsepower.
• Dynamically balanced armature for low vibration levels.
• Belt guards built right here in the USA with 13 G steel and premium grade expanded metal.
• For your safety, our belt guards are OSHA approved.
• 100% brass ASME safety valves with Teflon Seating.
• Extended tank water drain pipe plumbed out the front of the unit with a ¼” ball valve handle for easy tank draining.
• Taper lock style 2-groove pulleys (not single groove).
