AMGO PRO-10AWX Complete 10,000 Lbs Aligment Lift With Scissor 4-Post Lift

Brand:
AMGO Hydraulics
SKU:
PRO-10AWX Complete
Capacity:
10,000 Lbs

Factory Shipped.

Total Price:
$5,673.00 $4,538.00
(You save $1,135.00)

Shipping Calculated at Checkout
Shipping Calculated at Checkout

Factory Shipped.

AMGO PRO-10AWX Complete

PRO-10AWX the perfect choice of lift, with the combination of great performance and safety, for repairs, tire services, and wheel alignments for your commercial service. The PRO-10AWX, four post lift, is made stronger, more versatile, and easier To use while able to lift up to 10,000lbs.

Features

  •  Turn plates are not standard parts. Must be purchased separately
  •  10,000 lbs lifting capacity with small scissor lift
  •  Mechanical self-lock and cable-breaking protection
  •  Aircraft quality cable is used for synchronization
  •  Skid proof diamond platform
  •  Hydraulic cylinders are designed and made to high quality standards
  •  Optional platform extension kit can extend the platform for an additional 24″. Kit No: 40902
  •  Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on Electrical Components
Model PRO-10AWX
Lifting Capacity 10,000 lbs (4,536 kg)
Scissors Lifting Capacity 8,000 lbs (3,629 kg)
Lifting Time 45S
A:Overall Length (Inc.Ramps) 232 5/8″ (5910mm)
B:Overall Length (No.Ramps) 196 3/4″ (4998mm)
C:Overall Width 132 1/8″ (3356mm)
D:Width Between Columns 118 1/8″ (3000mm)
E: Lifting Height 75 3/8″ (1915mm)
F: Overall Height 86″ (2185mm)
G: Minimum Height 8 5/8″ (220mm)
H: Scissors Lifting height 16 1/2″ (420mm)
I: Scissors Length 67 3/4″~81 1/2″ (1720~2070mm)
Motor 2.0HP
Gross Weight 3,461 lbs (1,570 kg)
PRO-10AWX Diagram
